Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP for sale
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP
Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP

Top Air Outlet Condensing Unit (Using Xecom Compressor) 8-40HP

Occursum Top Air Outlet Condensing Unit (XECOM compressore adhibito) 8-40HP- tuam ultimam refrigerationem powerhouse, nunc a summo opere compressore XECOM acti. Machinatum ad latera aeris missionem, haec asperi, spatii salutaris unitas liberat singularem refrigerationem flexibilitatem per quinque iugis subtilitatis temperaturas: -30°C ad 0°C, -30°C ad 10°C, -40°C ad -5°C, -35°C ad 5°C, atque etiam ultra -40°C ad 0°C — faciens id specimen ad omnia a concreto pharmacopola frigido pharmacopola. Compressor XECOM fiducialem gradum industriae, strepitus ultra-low, et energiae eximiae efficientiam propter librum suum progressum designat — extenuando lapsum, maximizando uptime, et operando impensas tuas feriens. Pactum lateris missionis layout apte in stricta cubicula mechanica convenit, dum optimalem airflui distributionem procurans ut citius trahere-descendere et temperare constantem temperare possit. Operatio 24/7 in gravissimis ambitibus aedificata, haec unitas est particeps tua constans in frigore. Utrum centrum distributionis curris, escae plantae processus, vel porticus supermarket freezeris, XECOM-powered concretio unitatis aptat ad exigas necessitates tuas — nullas compromissas.

Contact Us
PREV：No previous article
DEINDE：Top Air Outlet Condensing Unit (Utens Panasonic Compressor) 8-40HP
Morbi condimentum
PDF Download
Unitas Exemplar AOSZXL-1.2HP AOSZXL-1.5HP AOSZXL-2HP AOSZXL-3HP AOSZXL-4HP AOSZXL-5HP AOSZXL-6H AOSZXL-8HP AOSZXL-10HP AOSZXL-8HP AOSZXL-10HP AOSZXL-12HP AOSZXL-15HP AOSZXL-20HP
Condensatum aeris exitus type Aer latus exitus Top aeris exitum
Evaporans Temperature / Refrigerant -40℃~-5℃/R404A
Virtus (V-Ph-Hz) 208~ 230/3/60
Compressor Type volumen compressor
Capacitas(P) 1.2 1.5 2 3 4 5 6 8 10 8 10 12 15 20
Exemplar XFL09B-D1-105 XFL10B-D1-105 XFL15B-D1-105 XFL20B-D1-105 XFL28B-D1-105 XFL35B-D1-105 XFL42B-D1-105 XFL51B-D1-105 XFL72B-D1-105 XFL51B-D1-105 XFL72B-D1-105 XFL80B-D1-105 XFL100B-D1-105 XFL120B-D1-105
Condenser ferrum et
motricium parametri 		Brand Orientisis Haile
Numerus 1 1 1 1 1 2 2 2 2 2 2 2 2 2
Virtus (W) 60 60 60 130 130 130 130 130 130 230 420W 420W 550W 780W
Fanspecifications 480X153 480X153 480X153 500X148 500X148 500X148 500X148 500X148 500X148 450 500 500 550 600
Airvolume (m³/h) 3500 3500 3500 5000 5000 5000X2 5000X2 5000X2 5000X2 4800X2 6550X2 6550X2 8600X2 11000X2
Specificatio aeris condensatoris Internum filum
Condensatio area (m) 11 11 19 30 40 50 60 80 100 80 100 120 150 200
Condenser tubus aeris φ9(25×21.65) φ9(25×21.65) φ7(25×21.65) φ7(25×21.65) φ9(25×21.65) φ7(25X21.65) φ9(25×21.65) φ7(21×18.19) φ9(21X×18.19) φ9(25×21.65) φ9(25×21.65) φ9(25×21.65) φ9(25×21.65) φ9(25×21.65)
Alveus volumen (L) 3 3 3 5 5 8 8 10 10 10 10 12 15 20
Specificatio valvularum globi et fistulae aeris conflati 6 12 Threaded nexum portum 10 16 Threaded nexum portum 12 19 sequela nexum portum 16 28 Welding iunctio port 16 28 Welding iunctio port 19 35 Welding iunctio port 19 42 Welding iunctio port
Commendatur frigus repono volumen ad frigus repono temperatus
range of 0 ~ -18 C (m³ 		10~15 10~15 15~20 20~50 40~60 50~100 60~ 120 80~ 140 100~150 80~ 140 100~150 120~200 150~300 200~400

Facultatem refrigerandi (W) 		Evaporatio in Temperatura Conditiones test: Redi temperies aeris 20℃, gradum subcoolescentis OK; Condensatio temperatus 40℃
-40℃ 751 878 1221 1696 2300 2903 3468 4282 5956 4282 5956 6785 8293 10261
-30℃ 1223 1430 1989 2763 3745 4727 5648 6974 9699 6974 9699 11050 13505 16710
-25℃ 1536 1795 2497 3468 5835 5934 7090 8755 12177 8755 12177 17217 16955 20978
-15℃ 2337 2732 3800 5278 7155 9032 10791 13325 18533 13325 18533 21113 25805 31928
-10℃ 2830 3309 4603 6393 8665 10938 13069 16138 22445 16138 22445 25570 31252 38667
-5℃ 3383 3955 5501 7640 10573 13073 15620 19287 26825 19287 26825 30560 37351 46213
Productum rationem longitudinis width×height (mm) 1000×440×575 1000×440×575 1000×440×575 1000×440×825 1000×440×825 1000×440×1225 1000×440×1225 1230×490×1350 1230×490×1350 1380×764× 1022 1344×764×922 1444×764× 1022 1444×894×1122 1644× 899× 1222
Productum rationem longitudinis width×height (mm) 1120×450×695 1120×450×695 1120×450×695 1120×450×955 1120×450×955 1120×450×1360 1120×450×1360 1350×490×1510 1350×490×1510 1580×880×1180 1530×880×1090 1645×900× 1170 1645× 1015× 1290 1830×1200×1390
Packaging dimensiones: length×width×height(mm) 49.5 49.5 49.5 51 51 53 53 56 56 56 56 59 63 65
sonitus dB(A) 48 48 51 71 75 90 99 122 129 / / / / /
Net pondus (kg) 55 55 58 78 82 97 106 130 137 / / / / /
Crassum pondus (kg) 725×410 725×410 725×410 725×410 725×410 725×410 725×410 690×450 690×450 906×725 870×725 970×755 970x855 970x860
Throttling fabrica Scelerisque expansion valvae (user provisum)
Suadeo utens ad scelerisque expansion valvae exemplum TES24# TES24# TES24# TES26# TES26# TGES6 TGES6 TGES9 TGES11 TGES9 TGES11 TGES13 TGES13 TGES13
Commendatur aer frigidior Thracam exemplum HS401AJ01.8 HS401AJ01.8 HS401AJ01.8 HS401AJ02.5 HS402AJ03.3 HS402AJ04.4 HS402AJ04.9 HS403AJ07.2 HS404AJ08.7 HS403AJ07.2 HS404AJ08.7 HS404AJ10.1 HS504AJ12.1 HS504AJ15
Nota: Ad refrigerandum unitatis institutionis effectum, commendatur ut fistulae aeris cum specificationibus non minoribus quam aeris frigidioris. Diameter variabilis tibiae aeneae adhiberi potest cum densante unitate connectens!

Unitas Exemplar AOSZXV-1.2HP AOSZXV-1.5HP AOSZXV-2HP AOSZXV-3HP AOSZXV-4HP AOSZXV-5HP AOSZXV-6H AOSZXV-8HP AOSZXV-10HP AOSZXV-8HP AOSZXV-10HP AOSZXV-12HP AOSZXV-15HP AOSZXV-20HP
Condensata aeris exitus genus Aer latus exitus Top aeris exitum
Evaporans Temperature / Refrigerant -35℃~5℃/R404A
Virtus (V-Ph-Hz) 208~ 230/3/60
Compressor Type Librum compressor
Capacitas(P) 1.2 1.5 2 3 4 5 6 8 10 8 10 12 15 20
Exemplar XFV09B-D1-181 XFV10B-D1-181 XFV15B-D1-181 XFV20B-D1-181 XFV28B-D1-181 XFV35B-D1-181 XFV42B-D1-181 XFV51B-D1-181 XFV72B-D1-181 XFV51B-D1-181 XFV72B-D1-181 XFV80B-D1-181 XFV100B-D1-181 XFV120B-D1-181
Condenser ferrum et
motricium parametri 		Brand Orientisis Haile
Numerus 1 1 1 1 1 2 2 2 2 2 2 2 2 2
Virtus (W) 60 60 60 130 130 130 130 130 130 230 420W 420W 550W 780W
Fanspecifications 480×153 480×153 480X153 500×148 500×148 500×148 500×148 500×148 500×148 450 500 500 550 600
Volumen (m³/h) 3500 3500 3500 5000 5000 5000×2 5000×2 5000×2 5000×2 4800×2 6550×2 6550×2 8600×2 11000×2
Specificatio aeris condensatoris Internum filum
Condensatio area (m) 11 11 19 30 40 50 60 80 100 80 100 120 150 200
Condenser tubus aeris φ9(25×21.65) φ9(25×21.65) φ7(25×21.65) φ7(25×21.65) φ9(25×21.65) φ7(25×21.65) φ9(25×21.65) φ7(21×18.19) φ9(21×18.19) φ9(25×21.65) φ9(25×21.65) φ9(25×21.65) φ9(25×21.65) φ9(25×21.65)
Alveus volumen (L) 3 3 3 5 5 8 8 10 10 10 10 12 15 20
Specificatio valvularum globi et fistulae aeris conflati 6 12 Threaded nexum portum 10 16 Threaded nexum portum 12 19 sequela nexum portum 16 28 Welding iunctio port 16 28 Welding iunctio port 19 35 Welding iunctio port 19 42 Welding connection
Commendatur frigus repono volumen forfrigidum repono
temperatus range of 0~-18 C (m³) 		10~15 10~15 15~20 20~50 40~60 50~100 60~ 120 80~ 140 100~150 80~ 140 100~150 120~200 150~300 200~400

Facultatem refrigerandi (W) 		Evaporatio Temperature Conditiones test: Redi temperies aeris 20℃, gradum subcoolescentis OK; Condensatio temperatus 40℃
-40℃ 751 878 1222 1697 2301 2904 3470 4284 5959 4284 5959 6788 8797 10266
-30℃ 1225 1429 1988 2761 3743 4725 5646 6971 9696 6971 9696 11046 13501 16704
-20℃ 1906 2228 3099 4305 5835 7366 8801 10867 15115 10867 15115 17219 21046 26039
-10℃ 2831 3309 4603 6393 8666 10940 13071 16139 22447 16139 22447 25573 31256 38672
0℃ 3989 4663 6486 9009 12212 15415 18418 22742 31630 22742 31630 36035 44042 54492
Productum rationem longitudinis width×height (mm) 1000×440×575 1000×440×575 1000×440×575 1000×440×825 1000×440×825 1000×440×1225 1000×440×1225 1230×490×1350 1230×490×1350 1380×764× 1022 1344×764×922 1444×764× 1022 1444×894×1122 1644× 899× 1222
Productum rationem longitudinis width×height (mm) 1120×450×695 1120×450×695 1120×450×695 1120×450×955 1120×450×955 1120×450×1360 1120×450×1360 1350×490×1510 1350×490×1510 1580×880×1180 1530×880×1090 1645×900× 1170 1645× 1015× 1290 1830×1200×1390
Packaging dimensiones: length×width×height(mm) 725×410 725×410 725×410 725×410 725×410 725×410 725×410 690×450 690×450 906×725 870×725 970×755 970x855 970×860
sonitus dB(A) 49.5 49.5 49.5 51 51 53 53 56 56 56 56 59 63 65
Net pondus (kg) 48 48 51 71 75 90 99 122 129 / / / /
Crassum pondus (kg) 55 55 58 78 82 97 106 130 137 / / / / /
Throttling fabrica Scelerisque expansion valvae (user provisum)
Suadeo utens ad scelerisque expansion valvae exemplum TES24# TES24# TES24# TES26# TES26# TGES6 TGES6 TGES9 TGES11 TGES9 TGES11 TGES13 TGES13 TGES13
Commendatur aer frigidior Thracam exemplum HS401AD02.5 HS401AD02.5 HS401AD02.5 HS401AD03.4 HS402AD04.2 HS402AD06.0 HS402AD06.6 HS403AD09.7 HS404AD11.9 HS403AD09.7 HS404AD11.9 HS404AD13.5 HS504AD16.5 HS504AD20.8
Nota: Ad effectum unitatis institutionis refrigerandum curare, commendatur uti fistulae aeris cum specificationibus non minoribus quam aeris frigidioris.
Diameter variabilis fistulae aeneae adhiberi potest cum connexione ad unitatem densationem!
